CY7C64215

enCoRe™ III Full-Speed USB Controller

Features

• Powerful Harvard-architecture processor
• Advanced peripherals (enCoRe™ III blocks)
• Complex peripherals by combining blocks
• Full-speed USB (12 Mbps)
• Flexible on-chip memory
• Programmable pin configurations
• Precision, programmable clocking
• Additional system resources
• Complete development tools
• For more, see pdf

Applications

•  PC human interface devices
• Mouse (optomechanical, optical, trackball)
• Keyboards
• Joysticks
•  Gaming
•  Game pads
• Console keyboards
•  General purpose
•  Barcode scanners
• POS terminal
• Consumer electronics
• Toys
• Remote controls
• USB to seria

enCoRe III Functional Overview

The enCoRe III is based on the flexible PSoC architecture and is a full-featured, full-speed (12-Mbps) USB part. Configurable analog, digital, and interconnect circuitry enable a high level of integration in a host of consumer, and communication applications.

This architecture enables the user to create customized peripheral configurations that match the requirements of each individual application. Additionally, a fast CPU, flash program memory, SRAM data memory, and configurable I/O are included in both 28-pin SSOP and 56-pin QFN packages.
