LCD Tester

Specifications:

Input voltage:DC 7-12V
Input current:≥3A
LCD voltage output:3.3V with protective alarm for short circuit
Backlights Output:Built-in Constant current output with protective alarm for short circuit
VGA input signal Maximal: Support 1920*1080 60HZ.

Features:

1 the use of simple and convenient, the Fifth version of the 55 LVDS LCD screen resolution
2 through the key switch digital tube display of the corresponding resolution of the value, you can point screen;
3 increase the LCD screen power supply short circuit protection function, prevent screen line plug or dislocation or liquid crystal screen power supply board damage, the digital tube display flashing after the screen line short circuit, the buzzer is long, short circuit after the resumption of normal (no longer than one minute long short circuit); ,
built in a variety of standard test plan, test chart function and role see below;
4 built in a variety of standard test plan, test chart function and role see below;
5 the test instrument panel comes with the operation instructions, use a glance;
6 with a key to automatic baking machine mode, convenient maintenance, factory assembly of the machine;
7 plug in an external VGA line automatically switch to the external VGA input signal display;
8 almost compatible with 95% 7 inch -84 inch LCD/LED LVDS LCD screen test;
9 general 12V LCD power supply, current size according to the actual need to test the screen and set;
