RT6575C RT6575D 6575C 6575D 5Y= 5X= QFN-20

Brand new RT6575C RT6575D  5Y= 5X= QFN-20

The RT6575A/B is a dual-channel step-down controller generating supply voltages for battery-powered systems. It includes two Pulse-Width Modulation (PWM) controllers adjustable from 2V to 5.5V, and two fixed 5V/3.3V linear regulators. Each linear regulator provides up to 100mA output current and 3.3V linear regulator provides 1% accuracy under 35mA. The RT6575A/B has an oscillator output to drive the external charge pump application. Other features include on-board power-up sequencing, a powergood output, internal soft-start, and soft-discharge output that prevents negative voltage during shutdown

Features:

• Support Connected Standby Mode for Ultrabook
• CCRCOT Control with 100ns Load Step Response
• PWM Maximum Duty Ratio > 98%
• 5V to 25V Input Voltage Range
• 2V to 5.5V Output Voltage Range
• 5V/3.3V LDOs with 100mA Output Current
• 1% Accuracy on 3.3V LDO Output
• Oscillator Driving Output for Charge Pump Application
• Internal Frequency Setting
• 300kHz/355kHz (CH1/CH2)
• Internal Soft-Start and Soft-Discharge
• 4700ppm/°C RDS(ON) Current Sensing
• Independent Switcher Enable Control
• Built-in OVP/UVP/OCP/OTP
• Non-Latch UVLO  Power Good Indicator
• RoHS Compliant and Halogen Free

Datasheet:

https://www.richtek.com/assets/product_file/RT6575C=RT6575D/DS6575CD-01.pdf
